LG 55VL5F Digital signage display 139.7 cm (55') LED 500 cd/m² Full HD Black

55", 1920 x 1080, Full HD, IPS, 2xHDMI, DVI-D, USB

Key Features

• Brightness(Typ.) : 500 cd/m²
• Bezel : 2.25 mm (T/L), 1.25 mm (B/R)
• Depth : 93.1 mm
• Interface : HDMI (2)/DP/DVI-D/USB/RS232C/RJ45/Audio/IR

Reasons To Buy

Seamless Large Screens with Ultra-Narrow Bezel

The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.

Image Gap Reduction

The VL5F series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

Higher Viewing Angle

Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5F series is high enough to display vivid colors throughout the screen with no distortion.

Wider Viewing Angle

It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5F series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.

Easy Color Adjustment

Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

Simple White Balance Adjustment

In conventional video walls, white balance was adjustable only in “full-white” mode, but the VL5F series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.

User-Friendly Menu Structure

The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-anderror when exploring desired functions and managing displays.

Intuitive GUI

The GUI(Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a larger font for better visibility, which is necessary when users want to control displays from relatively far distances.

Description

Incredible Immersion with Ultra-Narrow Bezel
The VL5F series provides all-encompassing screen immersion thanks to its ultra-narrow 3.5 mm bezel-to-bezel, while its outstanding IPS panel delivers a clear image from any angle. With its extremely attractive and highly functional design, it can be used to deliver advertising and information in a variety of business environments.

Specifications

Display
Touchscreen	No
Display technology	LED
Display diagonal	139.7 cm (55")
Display resolution	1920 x 1080 pixels
Display brightness	500 cd/m²
HD type	Full HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	500000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Panel life	50000 h
Native aspect ratio	16:9
Native refresh rate	60 Hz
Ports & interfaces
DisplayPorts out	1
USB port	Yes
DisplayPorts in	1
RS-232C	Yes
Wi-Fi	No
DisplayPorts quantity	2
Ethernet LAN	Yes
HDMI ports quantity	2
DVI port	Yes
DVI-D ports quantity	1
Audio (L/R) in	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
USB ports quantity	1
Design
Product design	Digital signage flat panel
Placement supported	Indoor/outdoor
Orientation	Horizontal/Vertical
Bezel width (top)	2.25 mm
Bezel width (bottom)	1.25 mm
Product colour	Black
Panel mounting interface	600 x 400 mm
VESA mounting	Yes
Performance
Purpose	Commercial
Wi-Fi	No
Panel life	50000 h
Power
Power consumption (typical)	130 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	135 kWh
Computer system
Computer system	No
Weight & dimensions
Width	1213.4 mm
Depth	93.1 mm
Height	684.2 mm
Weight	23.2 kg
Packaging data
Package width	1337 mm
Package depth	828 mm
Package height	239 mm
Package weight	30.5 kg
Remote control included	Yes
Packaging content
Remote control included	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Technical details
VESA mounting	Yes
Power supply type	Internal
DisplayPorts out	1
DisplayPorts in	1
Sustainability certificates	ENERGY STAR
Network
Wi-Fi	No
Ethernet LAN	Yes
Logistics data
Country of origin	South Korea
Harmonized System (HS) code	85285210
Features
Harmonized System (HS) code	85285210
Other features
Power supply type	Internal
DisplayPorts out	1
DisplayPorts in	1
Wi-Fi	No
Display technology	LED
Bezel width (top)	2.25 mm
Bezel width (bottom)	1.25 mm
Energy efficiency scale	A to G
